电机型号 | 额定电压 | KV值 | 最大拉力 （KG） | 动力套重量 （KG） | 持续工作电流 （A） | 电机温度 （℃） | 推荐拉力力效 （g/W） | 推荐单相轴拉力 （KG） | 推荐桨叶 （incn） |
H15 | 70V | 45KV | 72.65KG | / | 68A | / | 7.6-8.2 | 32-38KG | 63*24 |
工作电压 | 螺旋桨型号 | 油门(%) | 电流(A) | 转速(RPM) | 拉力(kg) | 扭矩(N.m) | 输入功率(W) | 输出功率(W) | 力效(g/W) |
| 70V/18S | 6324 | 33% | 17.8 | 1008 | 13.28 | 8.76 | 1226.2 | 924.6 | 10.8 |
35% | 19.7 | 1051 | 14.47 | 9.51 | 1358.7 | 1046.6 | 10.7 | ||
37% | 21.9 | 1096 | 15.81 | 10.36 | 1513.4 | 1189.0 | 10.4 | ||
39% | 24.5 | 1144 | 17.26 | 11.28 | 1351.2 | 1351.2 | 10.2 | ||
42% | 28.8 | 1217 | 19.60 | 12.77 | 1986.3 | 1627.3 | 9.9 | ||
45% | 33.6 | 1289 | 22.07 | 14.33 | 2321.1 | 1934.2 | 9.5 | ||
| 48% | 38.9 | 1360 | 24.63 | 15.95 | 2687.7 | 2271.4 | 9.2 | ||
51% | 44.7 | 1429 | 27.26 | 17.62 | 3086.1 | 2636.5 | 8.8 | ||
54% | 50.9 | 1497 | 29.95 | 19.32 | 3515.5 | 3028.5 | 8.5 | ||
57% | 57.6 | 1564 | 32.71 | 21.08 | 3979.5 | 3452.3 | 8.2 | ||
60% | 64.9 | 1630 | 35.54 | 22.89 | 4482.7 | 3906.9 | 7.9 | ||
63% | 72.9 | 1696 | 38.47 | 24.77 | 5030.3 | 4398.9 | 7.6 | ||
66% | 81.5 | 1763 | 41.51 | 26.72 | 5630.3 | 4932.7 | 7.4 | ||
69% | 91.1 | 1831 | 44.66 | 28.76 | 6289.8 | 5514.1 | 7.1 | ||
| 72% | 101.6 | 1901 | 47.93 | 30.89 | 7012.7 | 6148.9 | 6.8 | ||
| 75% | 113 | 1970 | 51.31 | 33.08 | 7802.0 | 6823.8 | 6.6 | ||
| 78% | 125.3 | 2040 | 54.75 | 35.32 | 8652.7 | 7544.8 | 6.3 | ||
| 81% | 138.3 | 2108 | 58.21 | 37.55 | 9550.3 | 8288.5 | 6.1 | ||
| 84% | 151.6 | 2173 | 61.61 | 39.71 | 10470.1 | 9035.6 | 5.9 | ||
| 87% | 164.7 | 2231 | 64.84 | 41.71 | 11372.5 | 9744.0 | 5.7 | ||
| 90% | 176.8 | 2281 | 67.77 | 43.46 | 12205.3 | 10380.3 | 5.6 | ||
| 100% | 197.1 | 2358 | 72.65 | 46.19 | 13608.4 | 11404.8 | 5.3 |
