Motor Model | Rated Voltage | KV Rating | Max.Thrust Force | Weight （KG） | Rated Current （A） | Temperature （℃） | Thrust Efficiency （g/W） | Axial Thrust （KG） | Propeller （incn） |
M8 | 46V | 100KV | 17.5KG | / | 20A | / | 8.7-6.9 | 5-7KG | 30*11 |
Voltage | Propeller | Throttle(%) | Current(A) | Speed(RPM) | Thrust(kg) | Torque(N.m) | Power Input(W) | Power Output(W) | Efficiency(g/W) |
| 48V/12S | 3010 | 30% | 3.8 | 1610 | 2.1 | 0.8 | 182.4 | 126.5 | 11.5 |
35% | 5.4 | 1833 | 2.8 | 1.0 | 257.8 | 189.7 | 10.7 | ||
40% | 7.2 | 2050 | 3.4 | 1.2 | 344.2 | 261.9 | 9.9 | ||
45% | 9.7 | 2300 | 4.3 | 1.5 | 465.6 | 366.1 | 9.1 | ||
50% | 13.0 | 2561 | 5.4 | 1.9 | 624.0 | 512.3 | 8.6 | ||
55% | 17.3 | 2802 | 6.6 | 2.3 | 830.4 | 677.8 | 7.9 | ||
60% | 21.3 | 3010 | 7.5 | 2.7 | 1022.4 | 854.2 | 7.3 | ||
65% | 25.9 | 3222 | 8.6 | 3.1 | 1242.2 | 1046.0 | 6.9 | ||
70% | 32.2 | 3395 | 9.9 | 3.5 | 1545.6 | 1244.4 | 6.4 | ||
75% | 38.6 | 3588 | 11.2 | 3.9 | 1850.9 | 1465.4 | 6.1 | ||
80% | 42.8 | 3790 | 12.2 | 4.3 | 2052.5 | 1706.7 | 5.9 | ||
85% | 52.5 | 3955 | 13.5 | 4.8 | 2520.0 | 1988.1 | 5.4 | ||
| 90% | 59.0 | 4100 | 14.8 | 5.3 | 2832.0 | 2279.9 | 5.2 | ||
| 95% | 69.3 | 4250 | 16.2 | 5.9 | 3326.4 | 2625.9 | 4.9 | ||
100% | 80.0 | 4450 | 17.5 | 6.4 | 3840.0 | 2983.8 | 4.6 |
